Description
Hikvision IDS-2CD7046G0-AP Overview
Monitor a room or hallway with the DeepinView iDS-2CD7046G0-AP 4MP Network Box Camera (No Lens) from Hikvision. Featuring a CS lens mount, this unit uses a 1/1.8" progressive scan CMOS sensor to capture 2680 x 1520 resolution video at 60 fps. Two-way audio is possible thanks to a built-in microphone, along with an audio input and output. A memory card slot accepts microSD/SDHC/SDXC cards up to 256GB (available separately). Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable.
This dome camera complies with ONVIF profiles G, S, and T, making it compatible with a wide range of surveillance devices.
IR cut filter for day and night functionality
CS lens mount
H.265+, H.265, H.264+, H.264, and MJPEG video compressions
Smooth streaming
Scalable Video Coding (SVC) for H.265/H.264 encoding
CBR and VBR
Target cropping
Image parameters switch
Picture overlay
140 dB wide dynamic range
Image enhancements include; backlight compensation, highlight compensation, 3D-DNR, defog, electronic image stabilization, and distortion correction
Region of interest supports four fixed regions for each stream
General functions include; anti-flicker, five streams and up to five custom streams, ePTZ, heartbeat, mirror, privacy masks, flash log, password reset via email, and pixel counter
Up to 32 users with three host levels (admin, operator, and user)
Up to 20 channels in simultaneous live view
1000M self-adaptive RJ45 Ethernet port
Self-adaptive RS-485 port
2 x alarm inputs and 2 x alarm outputs
Audio input and output
Built-in microphone
Environment noise filtering
Compatible with Internet Explorer 8 or higher (plug-in required), Chrome 57 or higher, Firefox 52 or higher, Safari 11 or higher, iOS, Android, iVMS-4200, Hik-Connect, HikCentral
Online upgradeable
Dual backup
Hardware and software reset
Analytics include; motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, audio exception detection, defocus detection, and counting
Deep Learning Functions
Multitarget detection supports simultaneous detection and capture of a human body and face (8 face features, 13 human body features)
Attribute-based people counting supports entrance/exit counting (track 30 targets simultaneously) and identification of people who pass repeatedly over a specified period of time
Hard hat detection detects up to 30 human targets simultaneously and supports up to 4 shield regions
Queue management detects numbers of people queuing up and the waiting time of each person, generates reports to compare the efficiency of different queues, and displays the changing status of a chosen queue with raw data export for further analysis
Perimeter protection includes; line crossing, intrusion, region entrance, and region exiting with alarm triggering by specified target types (human and vehicle) while minimizing false alarms
UPC: 842571135114
Hikvision IDS-2CD7046G0-AP Specs
Camera
| Sensor | 4 MP 1/1.8" CMOS |
| Lens Mount | CS |
| IR Cut Filter | Mechanical |
| Day/Night | Yes |
| Shutter Speed | 1/100000 to 1 Seconds |
Video
| Streaming Resolution | 2680 x 1520 at 60 fps |
| Supported Video Compression | H.264, H.264+, H.265, H.265+, MJPEG |
| Multi-View Streaming | Yes, 10 Streams |
| Video Outputs | 1 x BNC (Composite) |
Audio
| 1- or 2-Way Audio | Two-Way |
| Audio Formats | G.711, G.722.1, G.726, MP2L2, MP3, PCM |
| Built-In Mic | Yes |
| Audio I/O | Input: 1/8" / 3.5 mm Output: 1/8" / 3.5 mm |
Pan & Tilt
| Supported Control Protocols | Pelco-D Pelco-P RS-485 |
| Pan/Tilt | None |
Networking
| Security | Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection, Watermark |
| Supported Protocols | Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SFTP, SMTP, SNMP v1/v2c/v3 (MIB-II), SRTP, SSL/TLS, TCP, UDP, UPnP |
System Integration
| Application Programming Interface (API) | ONVIF Profiles G, S & T, ISAPI, SDK, ISUP |
| Analytics | Motion Detection, Video Tampering Alarm, Exception, Line Crossing Detection, Intrusion Detection, Region Entrance Detection, Region Exiting Detection, Unattended Baggage Detection, Object Removal Detection, Scene Change Detection, Audio Exception Detection, Defocus Detection, Counting, Multi-Target Detection, Attribute-Based People Counting, Hard Hat Detection, Queue Management, Perimeter Protection |
| Built-In Installation Aids | Pixel Counter |
| OS Compatibility | Android iOS *As of August, 2022: Check with manufacturer for the most up-to-date compatibility |
Sensors & Alarms
| Event Trigger | Yes |
| Event Action | Recording, Notification, Alarm |
| Data Streaming | Yes |
| Alarm I/O | 2 / 2 |
Hardware
| Memory | 2 GB RAM / 8000 MB Flash |
| Media/Memory Card Slot | Single Slot: microSD/microSDHC/microSDXC [256 GB Maximum] |
| Internal Storage | None |
| External Storage Options | NAS |
Power
| Power Source | AC, DC, PoE 802.3af (15 W) |
| Power Consumption | 12 W |
Environmental
| Operating Temperature | -22 to 140°F / -30 to 60°C |
| Startup Temperature | -22 to 140°F / -30 to 60°C |
| Storage Temperature | -22 to 140°F / -30 to 60°C |
| Operating Humidity | 0 to 95% (Non-Condensing) |
General
| Inputs/Outputs | 1 x RJ45 1 x Power 1 x BNC 1 x Serial 9-Pin (RS-485) |
| Video Management Software | iVMS-4200, Hik-Connect, HikCentral |
| Supported Languages | Brazilian Portuguese Bulgarian Croatian Czech Danish Dutch English Estonian Finnish French German Greek Hungarian Italian Japanese Korean Latvian Lithuanian Norwegian Polish Portuguese Romanian Russian Serbian Slovak Slovenian Spanish Swedish Thai Traditional Chinese Turkish Ukrainian Vietnamese |
| Material of Construction | Aluminum |
| Dimensions | H: 2.7 x W: 2.7 x L: 5.6" / H: 68.0 x W: 69.8 x L: 142.5 mm |
| Weight | 1.6 lb / 730 g |
Packaging Info
| Package Weight | 2.2 lb |
| Box Dimensions (LxWxH) | 12.4 x 5.7 x 5.5" |
