Hikvision IDS-7216HUHI-M2/S Overview
Record from and manage up to 16 local analog cameras at resolutions up to 8MP with the AcuSense iDS-7216HUHI-M2/S TurboHD 16-Channel DVR with 4TB HDD from Hikvision. HD-TVI (up to 8MP), AHD (up to 5MP), HD-CVI (up to 4MP), and CVBS signals are supported. Additionally, this DVR supports up to 16 IP cameras if Enhanced IP Mode is enabled and no analog cameras are used. It is equipped with two SATA ports that support HDD storage up to 20TB (4TB preinstalled). H.265+, H.264+, H.265, and H.264 video compressions keep file sizes manageable while maintaining the best quality possible. Two-way audio communication is supported.
This DVR features motion detection and perimeter protection with human/vehicle analysis. It has VGA and HDMI video outputs to connect to external monitors.
Hikvision IDS-7216HUHI-M2/S Specs
| Signal | AHD, Analog, HD-CVI, HD-TVI, IP |
| Number of Channels | 16 |
| Playback Resolution | HDMI: 4K UHD at 30 Hz 4 MP at 60 Hz VGA: 1080p at 60 Hz CVBS: PAL, NTSC |
| Recording Resolution | 8 MP |
| PTZ Support | Yes |
| Bit Rate | 32 kb/s to 10 Mb/s |
| IP Camera Support | 16 |
| Dual Streaming | Yes |
| Encoding Resolution | Main: 1080p, 720p, 4CIF, CIF, VGA, WD1, 3 MP, 4 MP, 5 MP, 8 MP Sub Stream: 1080p, 720p, 4CIF, CIF, VGA, WD1 |
| 2-Way Audio | Yes |
| A/V Inputs/Outputs | AHD, Analog, CVBS, Coaxitron, HD-CVI, HD-TVI: 16 x BNC (1 V p-p, 75 Ohm) 1 x HDMI 1 x VGA 1 x RCA Audio Input (2 V p-p, 1 Kilohm) 1 x RCA Audio Output (1 V p-p, 1 Kilohm, Linear) |
| Communication Inputs/Outputs | 1 x RJ45 Gigabit Ethernet 1 x RS-485 (Half-Duplex) 1 x USB-A 3.0 / 3.1/3.2 Gen 1 (Rear) 1 x USB-A 2.0 (Front) |
| Audio Inputs/Outputs | 1 Input 1 Output |
| System Connection | 2 x SATA |
| Wi-Fi | Yes |
| Remote Connections | 128 |
| Network Protocols | DDNS, DHCP, DNS, HTTPS, Hik-Connect, NFS, NTP, ONVIF, PPPoE, SADP, TCP/IP, UPnP, iSCSI |
| Max Frame Rate | 30 fps (1080p) |
| Supported Video Codecs | H.264, H.264+, H.265, H.265+ |
| Supported Audio Codecs | G.711U |
| Installed Drive | 4 TB |
| Max Capacity Supported | 20 TB (Total) 10 TB (Each Drive) |
| Recording Modes | Analytics, Motion |
| Search Modes | Smart Search |
| Event Trigger | Analytics, Motion |
| Power Consumption | Without HDD: 12 VDC at 5 A (19 W) |
| Operating Temperature | 14 to 131°F / -10 to 55°C |
| Operating Humidity | 10 to 90% |
| Built-In Display | None |
| Dimensions (W x D x H) | 15.0 x 12.6 x 1.9" / 380.0 x 320.0 x 48.0 mm |
| Weight | 4.6 lb / 2.1 kg |
| Package Weight | 8.43 lb |
| Box Dimensions (LxWxH) | 17.3 x 15.3 x 5.3" |
