COUGAR MX331 Mesh-X Overview
Bring connectivity and ample airflow to your next build with the MX331 Mesh-X Mid-Tower Case from COUGAR. Designed for use with ATX, micro-ATX, and mini-ITX boards, this case features an external 5.25" and two internal 2.5/3.5" drive bays. Users can also mount two 2.5" drives to the side of the case, while seven expansion slots accommodate adapter cards including GPUs up to 13.8". This case also supports CPU coolers and PSUs up to 6.1 and 7.9", respectively.
Coming with a preinstalled 120mm fan, the MX331 Mesh-X can be fitted with additional fans for increased airflow. Or, opt for liquid cooling and install a radiator up to 240mm on the front panel; 120mm radiators are supported on the rear and top panels. Removable filters at the top and bottom of the case help keep dust out, while the PSU shroud can be used to hide unsightly cables. In addition to metal side panels, the MX331 Mesh-X features a perforated front panel. A front I/O panel incorporates single USB 3.1 Gen 1 and USB 2.0 Type-A ports, as well as a microphone input and headphone output.
Aesthetic Airflow
Expansion-Minded
In the Box
- COUGAR MX331 Mesh-X Mid-Tower Case
- Mounting Hardware
- Limited 1-Year Warranty
COUGAR MX331 Mesh-X Specs
| Motherboard Support | ATX, Micro-ATX, Mini-ITX |
| External Drive Bays | 1 x 5.25" |
| Internal Drive Bays | 2 x 2.5/3.5" |
| Additional Drive Mounting | 2 x 2.5" (Side) |
| Expansion Slots | 7 x Full Height |
| Maximum GPU Length | 13.8" / 350 mm |
| CPU Cooler Height | 6.1" / 155 mm |
| Maximum PSU Length | 7.9" / 200 mm |
| Fan Mounting (Front) | 2 x 120 mm |
| Fan Mounting (Rear) | 1 x 120 mm |
| Fan Mounting (Side) | 1 x 80 mm Or 1 x 120 mm Or 1 x 200 mm |
| Fan Mounting (Top) | 2 x 120 mm |
| Fan Mounting (Bottom) | None |
| Fans Included (Front) | None |
| Fans Included (Rear) | 1 x 120 mm |
| Fans Included (Top) | None |
| Maximum Radiator Size (Front) | 240 mm |
| Maximum Radiator Size (Rear) | 120 mm |
| Maximum Radiator Size (Top) | 120 mm |
| Fans Included (Internal) | None |
| Filter Locations | Bottom, Top |
| Connections | 1 x USB Type-A (USB 3.1 / USB 3.2 Gen 1) 1 x USB Type-A (USB 2.0) |
| Media/Memory Card Slot | None |
| Audio Connections | 1 x 3.5 mm Input 1 x 3.5 mm Output |
| Display Connections | None |
| Windowed Panel | No |
| Built-In Lighting | No |
| Dimensions (W x H x D) | 8 x 18.9 x 17.4" / 204 x 481 x 443 mm |
| Weight | 10.1 lb / 4.6 kg |
| Package Weight | 12.67 lb |
| Box Dimensions (LxWxH) | 20.8 x 19.8 x 9.5" |
